Characteristics
Material
Sheet steel (EN 10130 DC01)
- Body: 1.2 mm
- Cover: 1.2 mm
Galvanized steel (EN 10346 DX51D+Z)
- Mounting plate: 1.5 mm
Surface Finishing
- RAL7035w powder coating
Protection Degree
- IP54 (TS 3033, EN 60529)
Others
- Digital control unit
- Programmable door and alarm output contact
- Two different power in same size/cut-out
- Large fin space for minimum dust accumulation
- Fast and easy installation
- Condensate drain output
- Maximum air inlet-outlet distance in cabinet side for optimum cooling performance
- Optional easy fixing ambient side dust filter kit
- Stainless steel versions on request
